App.1-7
Confidential
â– WSW04 (Transfer facility setting)
- Selectors 6 through 8: Break time length for flash function
These selectors set the break time length. This setting is effective only when the flash function is
selected for the
One Touch button by using the function switch.
Selector No. Function Setting and Specifications
1
Earth function in transfer facility
(Not used.)
2
3
Dual tone detection frequency in ICM
recording (Not used.)
4
Dual tone detection sensitivity in ICM
recording (Not used.)
5
Length of time added to time
designated by selectors 3 and 4 on
the WSW 24 (time between CML ON
and pseudo ring backtone return).
0: Not added
1: +4 seconds added
6
l
8
Break time length for flash function
No. 6 7 8
0 0 0: 80 ms
0 0 1: 100 ms
0 1 0: 110 ms
0 1 1: 120 ms
1 0 0: 200 ms
1 0 1: 250 ms
1 1 0: 500 ms
1 1 1: 700 ms
Note:
Selectors 1 and 5 through 8 are not applicable in those countries where no transfer facility is
supported.
