■ WSW18 (Function setting 3)
- Selector 1: Addition of registration of station ID for PC-FAX
The sending state is as follows whether add the station ID in the PC side or not.
The data do not add the station ID in the PC side.
→ Follow the Selector 1 in WSW 18, add the station ID or not.
The data add the station ID in the PC side.
→ Let it lie in the main body side.
- Selectors 2 and 3: Detection enabled time for CNG and no tone
After the line is connected via the external telephone or by picking up the handset of the machine, the
machine can detect a CNG signal or no tone for the time length specified by these selectors
. The
setting specified by these selectors becomes effective only when selector 8 on WSW20 is set to “1.”
- Selector 6: Registration of station ID
Setting this selector to “0” permits the registration of station ID for Austrian and Czech models.
- Selectors 7 and 8: Tone sound monitoring
These selectors set monitoring specifications of the tone sound inputted from the line.
Selector No. Function Setting and Specifications
1
Addition of registration of station ID
for PC-FAX
0: Add
1: Not add
2
3
Detection enabled time for CNG and
no tone
No. 2 3
0 0: 40 sec.
0 1: 0 sec. (No detection)
1 0: 5 sec.
1 1: 80 sec.
4
5
Not used.
6 Registration of station ID
0: Permitted
1: Prohibited
7
8
Tone sound monitoring
No. 7 8
0 0: No monitoring
0 1: No monitoring
1 0: Up to phase B at the calling
station only
1 1: All transmission phases both at
the calling and called stations
