App.1-22
Confidential
■ WSW19 (Transmission speed setting)
- Selectors 1 through 6: First and last choices of transmission speed for fallback
These selectors are used to set the MODEM speed range. With the first transmission speed choice
specified by selectors 1 through 3, the machine attempts to establish the transmission link via the
MODEM. If the establishment fails, the machine automatically steps down to the next lowest speed
and attempts to establish the transmission link again. The machine repeats this sequence while
stepping down the transmission speed to the last choice specified by selectors 4 through 6.
If the MODEM always falls back to a low transmission speed (e.g., 4,800 bps), set the first
transmission speed choice to the lower one (e.g., modify it from 12,000 bps to 7,200 bps) in order to
deactivate the high-speed MODEM function and reduce the training time for shorter transmission time.
Generally, to save the transmission time, set the last transmission speed choice to a higher one.
- Selector 7: V.34 mode
If this selector is set to “0,” selectors 5 through 8 on the WSW38 through WSW40 and on WSW41,
will become effective.
Selector No. Function Setting and Specifications
1
l
3
First transmission speed choice for
fallback
No. 1 2 3
No. 4 5 6
0 0 0: 2,400 bps
0 0 1: 4,800 bps
0 1 0: 7,200 bps
0 1 1: 9,600 bps
1 0 0: 12,000 bps
1 0 1: 14,400 bps
1 1 0: 14,400 bps
1 1 1: 14,400 bps
4
l
6
Last transmission speed choice for
fallback
7 V.34 mode
0: Permitted
1: Prohibited
8 V.17 mode
0: Permitted
1: Prohibited
