App.1-28
Confidential
â–  WSW27 (Function setting 5)
- Selector 2: Ringer OFF setting
This selector determines whether or not the ringer can be set to OFF.
â–  WSW28 (Function setting 6)
- Selectors 1 through 6: Transmission level of DTMF high-/low-band frequency signal
These selectors are intended for the manufacturer who tests the machine for the Standard.
Never access them.
Selector No. Function Setting and Specifications
1 Not used.
2 Ringer OFF setting
0: Yes
1: No
3
Automatic playback of OGM when
switched to the TAD mode
(Not used.)
4
Detection of distinctive ringing pattern
(Not used.)
5 Not used.
6 Recording quality (Not used.)
7
Recording time for high recording
quality (Not used.)
8 Not used.
Note:
Selectors 4 and 5 are applicable to the USA models only.
Selector No. Function Setting and Specifications
1
l
3
Transmission level of DTMF
high-band frequency signal
No. 1 2 3
0 0 0: 0 dB
0 0 1: +1 dB
0 1 0: +2 dB
0 1 1: +3 dB
1 0 0: 0 dB
1 0 1: -1 dB
1 1 0: -2 dB
1 1 1: -3 dB
4
l
6
Transmission level of DTMF
low-band frequency signal
No. 4 5 6
0 0 0: 0 dB
0 0 1: +1 dB
0 1 0: +2 dB
0 1 1: +3 dB
1 0 0: 0 dB
1 0 1: -1 dB
1 1 0: -2 dB
1 1 1: -3 dB
7
8
Not used.
