A number of actions can be carried out in the Measurements List dialog box including searching for measurements
using a variety of filters, viewing measurement sample and process parameters, viewing measurement results,
printing reports, exporting measurements to a file, and reprocessing measurements.
5.1 Viewing Analysis Results
View existing measurement results by double-clicking on the measurement or by highlighting the row
containing the desired measurement and then clicking on the VIEW button in the bottom right-hand corner
of the Measurement List dialog box. This will open a Measurement dialog box containing all of the relevant data
results for the selected measurement (see “Results Displayed in the Measurement Dialog Box”).
5.2 Searching for Measurements
It is possible to search for measurements using a number of different filter criteria including sample drawing
date, process date, Reactor ID, and Sample ID in the Filter By area at the top of the Measurement List dialog box.
To search for measurements based on the sample drawing date or the process date, for example, do the following:
1
Click on the drop-down menu button next to the Sample Drawing Date From or Process Date From
sections. A calendar will appear in which the desired starting date for filtering can be selected.
2
When a date has been selected, a check will appear in the checkbox next to the date to indicate that a filter
is active based on that date.
3
Click on the drop-down menu button next to the date in order to select the desired ending date.
4
Once the dates for filtering the measurements have been selected, click on the FIND button in the upper
right-hand corner of the Measurement List dialog box.
5
All of the measurements that match the dates given for sample drawing (using the Sample Drawing
Date From section), or that were run within the dates specified in the Process Date From section, will
be displayed in the measurement list in the bottom half of the dialog box.
■
It is possible to select measurements with regard to both sample drawing date and process date. If the desired
dates for both the sample drawing dates and process dates are selected, only those measurements that meet all
4 date criteria will be displayed when the FIND button is clicked on.
Measurements can also be searched for, based on Reactor ID and/or Sample ID by filling in the information in
these sections of the Filter By area. In addition, measurements can be searched for, based on user by typing in
the user name in the User section, by Workarea (using the drop-down menu in the Workarea section), by data
set (in the DataSet area), and by Cell Type (using the drop-down menu in the Cell Type section).
If a measurement has been reprocessed, the original and all reprocessed versions of the measurement will be
listed. The data set version of a particular measurement that has been selected as the Effective data set will
have a check in the checkbox of the DSEffective column. The original data set of a particular measurement
will have a check in the checkbox of the DSOriginal column (see “Effective Data Sets”).
The Measurement List dialog box displays a maximum of 1000 measurements at a time. If a measurement
is not displayed in the Measurement List dialog box, use the Filter By area to search for the measurement.
