10.5.5. Viewing an Existing Cell Type
Select the Cell Type to be viewed from the list of Cell Types at the top of the Cell Type List dialog box and then
click on the VIEW button. The Ce ll Type dialog box will open in which the information for focus point (Focus
Offset) and sedimentation time (Sedimentation Duration) can be viewed. Click on the LIVE OPERATOR
button in order to view other parameters within the Live Operator dialog box for that Cell Type.
10.5.6. Deleting an Existing Cell Type
Select the Cell Type to be deleted from the list of Cell Types at the top of the Cell Type List dialog box and then
click on the DELETE button. A confirmation box will appear. If confirmed, the Cell Type will be deleted and
disappear from the list.
All parameters of the measurements are logged. Deleted Cell Types have no influence on future measurements,
but the parameters of deleted Cell Types used for past measurements will still appear in the printed reports
of those measurements.
10.5.7. Working With the Live Operator
The Live Operator dialog box can be opened via the Cell Type List dialog box, the Cell Type dialog box, and
the Measurement dialog box. If the LIVE OPERATOR button in a Measurement dialog box containing specific
results is clicked on, the Live Operator will open with the images of that measurement already loaded. If the Live
Operator is opened via the Cell Type or Cell Type List dialog boxes, the first measurement in the Measurement
List dialog box will be loaded.
In the Live Operator dialog box, some of the 11 parameters are displayed on the screen at the same time.
Parameters at first not visible can be scrolled into view using the scroll bar under the Operator Parameter
display. The table below displays the positions and settings of the 11 Operator parameters and the default
settings for the three pre-installed Cell Types. See also “Description of the Individual Operator Parameters” for a
detailed description of each parameter.
Identifier Minimum Maximum Min. Size Std. Size Max. Size
ClassificationBias -20 20 -1 0 -8
CMinSize [µm] 0 100 3 7 10
LCAppearance -10 10 4 0 0
DCAppearance -10 10 0 0 -1
CMaxSize [µm] 0 100 70 70 100
AggrMinSize [µm] 8 50 12 12 15
BorderWidth 0 1000 10 10 10
AggrMaxSize [µm] 10 200 100 100 100
LCAggrApp -10 10 5 0 0
DCAggrApp -10 10 6 0 -3
MinPollutionArea [µm] 50 1000 100 100 100
Table 7: List of the Operator parameters
Administrator Functions
Adjustment of the Image Analysis using the Live Operator
