Cedex HiRes - Fuse Exchange and Component Maintenance

123
Maintenance and Care
D
D
9 Exchanging the Fuse in Cedex HiRes Analyzers from
Serial Number G037DA101
Cedex HiRes Analyzers from serial number G037DA101 contain a fuse that must be exchanged when the fuse is
blown. The Cedex HiRes Analyzer delivery package includes a set of 10 replacement fuses.
Before inspecting or replacing the fuse, the power cord must be disconnected entirely from the power supply.
1
Turn off the Analyzer and disconnect the power cord from the power supply.
2
The fuse is located at the back of the Analyzer.
3
Remove the fuse holder from the instrument by turning the fuse holder cap counter-clockwise.
4
Remove the blown out fuse and insert the new fuse into the fuse holder cap.
Use only the fuses provided with the Analyzer. See information about the fuses, below.
ccc
Exchanging the Fuse in Cedex HiRes Analyzers from Serial Number G037DA101
