52
Cedex HiRes Analyzer Operator’s Guide
C
C
6 Editing Existing Analysis Results/Data Sets
The Cedex HiRes Software allows for existing measurement results or data sets to be modified and reprocessed.
These changes are done on existing Software data (image and analysis results) and, therefore, do not require
any adjustments to the Analyzer. Existing measurement results can be edited via the REPROCESS button in the
lower right-hand corner of the Measurement List dialog box.
6.1 Reprocessing Measurements
Reprocessing existing measurement results/data sets (i.e., viewing a set of image data and evaluating them with
new analysis parameters), can be done in the Reprocess mode, which is only accessible to authorized system
users.
The reprocess mode offers the following options:
c
Enter, modify, or delete a comment.
c Change the dilution.
c Change the Cell Type.
To reprocess a measurement:
1
Open the Measurement List dialog box by clicking on the LIST button in the Shortcuts area of the Cedex
Control Center.
2
Highlight the row of the measurement to be reprocessed and click on the REPROCESS button in the
lower right-hand corner. A Measurement dialog box will open containing all of the result data for that
measurement.
3
Enter a new name for the data set in the Data Set section of the Sample Parameters area.
4
Make the desired changes. Changes can be made with regard to the comment, dilution factor, and Cell Type
in the appropriate sections of the Sample Parameters and Processing Parameters areas.
Do not select the Cell Type option Illumination Test, if it is available. This Cell Type is designed for
service purposes only and is not intended for analysis of cells. The parameters for this Cell Type should
not be changed.
5
Click on the REPROCESS button in the center of the Measurement dialog box to start the reprocessing of
the measurement based on the new parameters.
6
When the reprocessing is finished, a dialog box will open asking whether the new data set should be the
effective data set (see “Effective Data Sets”).
■
A new data set is available once the evaluation has been completed. All changes can be retraced by viewing
previously created data sets, which are shown in the Measurement List dialog box.
The reprocessing procedure creates additional data sets. Original data is not overwritten.
Reprocessing of previous measurements cannot be performed while the Cedex HiRes Analyzer is measuring
a cell sample.
Editing Existing Analysis Results/Data Sets
The REPROCESS Button
