61
Software
C
C
8 Cultivation Time Chart
In the Cultivation Time Chart, the growth patterns of cell cultures can be graphically evaluated. It is also possible
to export and print out the data.
The CTC Views dialog box required for creating a Cultivation Time Chart is opened by clicking on the CTC
button in the Shortcuts area of the Cedex Control Center or by selecting the Cultivation Time Chart option
in the Measurements menu. In the CTC Views dialog box, charts can be created, viewed, edited, exported, and
deleted.
A collection of data used for the creation of a particular chart is called a View. Each View can have up to
5 separate series of measurements for comparison of data.
Step-by-step instructions for creating CTC Views and analyzing patterns of growth over time are provided in
Section C, Chapter 1, “Monitoring Growth of Cells Over Time” in the Cedex HiRes Analyzer User Training Guide.
8.1 The CTC View Dialog Box
The CTC Views dialog box has two areas (see Figure 25):
c
The View area is used for viewing, exporting, creating, and deleting charts. The Filter By section located at
the top of this area is used for finding previously created Cultivation Time Charts.
c The Series of measurements belonging to selected view area is used for creating, editing, listing, or deleting
the various measurement series belonging to the View highlighted in the View area.
Figure 25: CTC Views dialog box
Cultivation Time Chart
The CTC View Dialog Box
