Additional Applications
C
C
3
To display curves for other types of measurement results, choose the desired parameters in the
Data Selection area. The following values can be selected for display:
c Viable Cell Conc.: Viable cell concentration [× 10
5
cells/mL].
c Total Cell Conc.: Total cell concentration [× 10
5
cells/mL].
c Viability: Percent viability [%].
c Total Cell Count: Total number of all cells counted.
c Avg. Compactness: Average compactness of living cells [without unit].
c Avg. Diameter: Average diameter of living cells [µm].
c Aggregate Rate: Percent of cells found in aggregates [%].
c Dead Cell Conc.: Dead cell concentration [× 10
5
cells/mL].
c Viable Cell Count: Total number of viable cells counted.
c Dead Cell Count: Total number of dead cells counted.
c Total Object Count: Total number of objects counted.
A graph will be generated showing the measurement results for the selected parameters.
4
Click on the log option button to display the Y-axis in a logarithmic scale.
Click on the lin option button to display the Y-axis in a linear scale.
5
The X-axis units can be displayed as either days [d] or hours [h].
Click on Time [d] below the X-axis to switch between days and hours. The X-axis calibration is automatically
recalculated.
6
To view detailed information on a measurement point, position the mouse pointer exactly over a point
in the diagram.
The information displayed includes the date and time of the measurement as well as the result.
7
Enlarge the graphic representation or scale it down again using the mouse.
For more information on enlarging graphs and diagrams, see Enlarging the Histograms in the
Cedex HiRes Analyzer Operator’s Guide.
n
Monitoring Growth of Cells Over Time
Result Analysis
