Performing a Measurement — (October 2017)
9
Select the desired precision level in the Precision drop-down list:
c Minimum: 3 images are used for the analysis.
c Normal: 6 images are used for the analysis.
c Superior: 8 images are used for the analysis.
c Maximum: 11 images are used for the analysis.
10
Prepare the sample. The Cedex HiRes Analyzer requires a volume of 300 µL +/- 10%.
Any greater variation in sample volume will lead to inaccurate results.
11
Attach the Cedex Sample Cup containing the sample to the single sample port, or place it
in the appropriate
sample cup position on the Multi Sample Tray. For a single sample port,
the sample cup is correctly attached
when it is in an upright position directly beneath the
sample port, and the capillary tube almost reaches the base of the sample cup.
12
Click on the START MEASUREMENT button to start the measurement.
13
When the measurement is finished, the top section of the Result Data area in the
Measurement dialog box displays the overall results from the measurement.
The bottom section displays, in succession, the results from each image taken.
■
Logging out and/or shutting down
1
Open the Hardware Management dialog box (HWM button on the Cedex Control Center).
2
Click on LM Shutdown to shut down the Liquid Management system.
3
Click on the LOGOUT button on the Cedex Control Center to log out of the Cedex Control
Center. The Cedex Control Center software program will be ended, and the Login dialog
box will
reappear.
4
Alternatively, shut down the software by selecting Exit under the System menu or by clicking
on
to close the Cedex Control Center dialog box.
5
The security query, “Do you really want to exit the Cedex Control Center?“, will appear.
Click on Yes to shut down the program.
6
For a Multi Sampler, a sample cup should always be left in the DefaultCup position on the
Multi Sample Tray (see Quick Guide “Working with the Multi Sampler”). For a single sample
port, the sample cup from the last measurement should remain attached to the sample port
during the entire shutdown procedure and should only be removed when a new sample cup
has been attached for the next measurement.
■
