24
Cedex HiRes Analyzer Operator’s Guide
A
A
Technical Specifications of the Cedex HiRes Control Unit
The following table describes the current technical specifications of Cedex HiRes Control Units. Both types of
Control Units are operational with Cedex SW 2.4 and with the Analyzer.
The specifications may be modified at any time without prior information from Roche.
Control Unit Type Rp5700 Rp5810
Processor type Intel
®
Pentium
®
Dual CPU E2160 @1.8GHz Intel
®
i5-4750S CPU @ 2.90 GHz
RAM 2GB 8GB (3.39GB usable)
Operating System Windows
®
Embedded Standard
(Based on Windows
®
7)*
Windows
®
Embedded Standard
(Based on Windows
®
7)*
System Type 32-Bit Operating System 32-bit Operating System
Hard drive capacity 2× 150 GB 1× 500 GB divided on 2 partitions
Network port 1× LAN 10 / 100 /1000 Base T Ethernet
port for the use of the Cedex Remote
Control functionality
1× LAN 10 / 100 /1000 Base T Ethernet
port for the use of the Cedex Remote
Control functionality
USB 2 free ports 2 free ports
Optical Drive CD-RW, DVD+RW, DVD+R DL,
DVD-RW, DVD-R DL
CD-RW, DVD+RW, DVD+R DL,
DVD-RW, DVD-R DL
Monitor 1024 × 768 pixels 1280 × 1024 pixels
* The provided versions of Windows
®
only include features required for the operation of the Analyzer.
Standard Windows features are limited to ensure IT safety of the system.
Table 2
Multi Sampler
Number of samples 1 to 20
Average measurement
period for 20 samples < 90 min
Dimensions
Height: 170 mm
Width: 190 mm
Depth: 260 mm
completely integrated into the Cedex HiRes Analyzer
Energy requirements 24 VDC, 2.0 A
derived from internal supply
Energy consumption max. 10 W
Table 3
Technical Specifications of the Analyzer
