Chrysler 62TE - Page 100

Fig. 156: Differential Out And In
Courtesy of CHRYSLER LLC
54. Install the differential, bearing cups, shim, seals and oil slinger into case.
Fig. 157: Differential Cover
Courtesy of CHRYSLER LLC
55. Install the differential cover.
2009 Chrysler Town & Country LX
2009 AUTOMATIC TRANSMISSION 62TE - Service Information - Grand Caravan, Town & Country
