Chrysler 62TE - Input Shaft Snap Ring; Return Spring & Snap Ring

Fig. 320: Input Shaft Snap Ring
Courtesy of CHRYSLER LLC
2. Install input shaft snap ring (3).
Fig. 321: Return Spring & Snap Ring
Courtesy of CHRYSLER LLC
1 - INPUT SHAFT
2 - SCREWDRIVER (DO NOT SCRATCH BEARING
SURFACE)
3 - SNAP RING
4 - O-RINGS
5 - SEALS
1 - OD/REVERSE PISTON
2 - RETURN SPRING
2009 Chrysler Town & Country LX
2009 AUTOMATIC TRANSMISSION 62TE - Service Information - Grand Caravan, Town & Country
