Chrysler 62TE - Clutch Pack Disassembly

Fig. 63: 2/4 Clutch Retainer Snap Ring
Courtesy of CHRYSLER LLC
33. Setup the Spring Compressor 5058A (1), Compress 2/4 clutch return spring (4) (just enough to remove
snap ring) and remove snap ring (3).
Fig. 64: 2/4 Clutch Retainer
Courtesy of CHRYSLER LLC
1 - SPRING COMPRESSING 5058A
2 - SCREWDRIVER
3 - SNAP RING
4 - 2/4 CLUTCH RETAINER
NOTE: Verify that Compressor 5058A is centered properly over the 2/4 clutch
retainer before compressing. If necessary, fasten the 5058A bar to the
bellhousing flange with any combination of locking pliers and bolts to
center the tool properly.
