Chrysler 62TE - Input Shaft to Input Clutch Hub Snap Ring

19. Using Disk 6057 (4) and an arbor press (1), compress return OD/Reverse piston return spring just enough
to remove snap ring (3).
Fig. 316: Input Shaft To Input Clutch Hub Snap Ring
Courtesy of CHRYSLER LLC
20. Remove input shaft to input clutch hub snap ring (3).
5 - OD/REVERSE PISTON
6 - RETURN SPRING
1 - INPUT SHAFT
2 - SHARP-POINTED TOOL
3 - SNAP RING
4 - O-RINGS
5 - SEALS
2009 Chrysler Town & Country LX
2009 AUTOMATIC TRANSMISSION 62TE - Service Information - Grand Caravan, Town & Country
