Chrysler 62TE - Ignition Key;Switch Positions

Fig. 568: Ignition Key/Switch Positions
Courtesy of CHRYSLER LLC
The Brake Transmission Shifter/Ignition Interlock (BTSI) is a solenoid operated system that prevents the
transmission gear shifter from being moved out of PARK without a driver in place.
OPERATION
OPERATION
1 - LOCK
2 - ACC
3 - ON
4 - START
