Fig. 574: Turbine
Courtesy of CHRYSLER LLC
The turbine (1) is the output, or driven, member of the converter. The turbine is mounted within the housing
opposite the impeller, but is not attached to the housing. The input shaft (3) is inserted through the center of the
impeller and splined into the turbine. The design of the turbine is similar to the impeller, except the blades of
the turbine are curved in the opposite direction.
STATOR
1 - TURBINE VANE
2 - ENGINE ROTATION
3 - INPUT SHAFT
4 - PORTION OF TORQUE CONVERTER COVER
5 - ENGINE ROTATION
6 - OIL FLOW WITHIN TURBINE SECTION
2009 Chrysler Town & Country LX
2009 AUTOMATIC TRANSMISSION 62TE - Service Information - Grand Caravan, Town & Country
