. 68: Low/Reverse Reaction Plate
Courtesy of CHRYSLER LLC
38. Remove low/reverse reaction plate (1).
Fig. 69: One Low/Reverse Clutch Disc
Courtesy of CHRYSLER LLC
39. Remove one low/reverse clutch disc (1).
Fig. 70: Low/Reverse Reaction Plate Snap Ring
Courtesy of CHRYSLER LLC
1 - LOW/REVERSE REACTION PLATE (FLAT SIDE UP)
1 - ONE DISC FROM LOW/REVERSE CLUTCH
1 - SCREWDRIVER
2009 Chrysler Town & Country LX
2009 AUTOMATIC TRANSMISSION 62TE - Service Information - Grand Caravan, Town & Country
