Chrysler 62TE - Oil Transfer Tubes; Transfer Tube O-Rings

Fi
g
. 48: Oil Transfer Tubes
Courtesy of CHRYSLER LLC
16. Remove valve body (1) from oil transfer tubes and manual valve (3) from rooster comb.
Fig. 49: Transfer Tube O-Rings
Courtesy of CHRYSLER LLC
17. Remove oil transfer tubes (2) from the case.
2009 Chrysler Town & Country LX
2009 AUTOMATIC TRANSMISSION 62TE - Service Information - Grand Caravan, Town & Country
