of CHRYSLER LLC
18. Remove the transaxle upper bellhousing-to-block bolts (3).
Fig. 24: Ground Cable
Courtesy of CHRYSLER LLC
19. Raise the vehicle on the hoist.
20. Remove the bolt (2) holding the ground cable (3) to the transaxle.
21. Remove tie strap (1) to trans valve body pan.
22. Remove both halfshafts. Refer to Differential and Driveline/Half Shaft - Removal .
23. Remove the front and both side splash shields. Refer to Body/Exterior/SHIELD, Splash
- Removal .
2009 Chrysler Town & Country LX
2009 AUTOMATIC TRANSMISSION 62TE - Service Information - Grand Caravan, Town & Country
