Chrysler 62TE - Holding Clutches

Courtes
y
of CHRYSLER LLC
The planetary gear train is located between the input clutch assembly and the rear of the transaxle case. The
p
lanetary gear train consists of two sun gears (1,5), two planetary carriers, two annulus (ring) gears (4,6), and
one output shaft.
OPERATION
OPERATION
The planetary geartrain utilizes two planetary gear sets that connect the transmission input shaft to the output
shaft. Input and holding clutches drive or lock different planetary members to change output ratio or direction.
HOLDING CLUTCHES
DESCRIPTION
DESCRIPTION
1 - FRONT SUN GEAR ASSEMBLY
2 - #6 THRUST BEARING
3 - #7 THRUST BEARING
4 - REAR CARRIER/FRONT ANNULUS ASSEMBLY
5 - REAR SUN GEAR
6 - FRONT CARRIER/REAR ANNULUS ASSEMBLY
2009 Chrysler Town & Country LX
2009 AUTOMATIC TRANSMISSION 62TE - Service Information - Grand Caravan, Town & Country
