Chrysler 62TE - Pry Reverse Clutch Reaction Plate; Reverse Clutch Assembly

3. Remove reverse clutch snap ring (3).
Fig. 305: Pry Reverse Clutch Reaction Plate
Courtesy of CHRYSLER LLC
4. Pry up and remove reverse clutch reaction plate (1).
Fig. 306: Reverse Clutch Assembly
Courtesy of CHRYSLER LLC
1 - REVERSE CLUTCH REACTION PLATE
2 - SCREWDRIVER
3 - SCREWDRIVER
2009 Chrysler Town & Country LX
2009 AUTOMATIC TRANSMISSION 62TE - Service Information - Grand Caravan, Town & Country
