Chrysler 62TE - Battery

Fig. 15: Battery
Courtesy of CHRYSLER LLC
1. Open hood.
2. Disconnect the battery cables (1).
3. Remove the battery hold down bolt (3) and remove the battery (2).
4. Remove the clips holding harness and ground cable to the battery tray.
5. Remove the battery tray.
2009 Chrysler Town & Country LX
2009 AUTOMATIC TRANSMISSION 62TE - Service Information - Grand Caravan, Town & Country
