Chrysler 62TE - Low Clutch Measurement; Underdrive Compounder Bearing

Fig. 388: Low Clutch Measurement
Courtesy of CHRYSLER LLC
10. Using a Dial Indicator and air pressure measure the low clutch clearance, the clearance should be 0.48 -
0.76 mm (0.019 - 0.030 in.). Install desired selectable snap ring to achieve correct clearance.
Fig. 389: Underdrive Compounder Bearing
2009 Chrysler Town & Country LX
2009 AUTOMATIC TRANSMISSION 62TE - Service Information - Grand Caravan, Town & Country
