of CHRYSLER LLC
11. Using Installer 6756 (2) and a Press (1), install the underdrive compounder bearing (3) to transfer shaft.
Fig. 390: Transfer Shaft
Courtesy of CHRYSLER LLC
12. Install new seal rings on the transfer shaft.
13. Install the transfer shaft (1) onto the low clutch (2).
2009 Chrysler Town & Country LX
2009 AUTOMATIC TRANSMISSION 62TE - Service Information - Grand Caravan, Town & Country
steve
Monday, May 23, 2011 1:26:10 PM Page 232 © 2006 Mitchell Repair Information Company, LLC.
