The 62TE has six accumulators and are all located in the case under the valve body.
OPERATION
OPERATION
The function of an accumulator is to cushion the application of a frictional clutch element. When pressurized
fluid is applied to a clutch circuit, the application force is dampened by fluid collecting in the respective
accumulator chamber against the piston and spring(s). The intended result is a smooth, firm clutch application.
REMOVAL
REMOVAL
Fig. 301: Accumulators
Courtesy of CHRYSLER LLC
1. Remove the valve body. See Transmission and Transfer Case/Automatic - 62TE/VALVE BODY -
Removal.
2. Remove the accumulator as needed.
1 - UD ACCUMULATOR 5 - LC
ACCUMULATOR
2 - 2/4 ACCUMULATOR 6 - DC
ACCUMULATOR
3 - LR ACCUMULATOR
7 - OD
ACCUMULATOR
4 - 2/4 CLUTCH OIL SUPPLY SEAL -
