Chrysler 62TE - Inner Separator Plate; Outer Separator Plate

Fig. 602: Inner Separator Plate
Courtesy of CHRYSLER LLC
3. Install the inner separator plate (1).
Fig. 603: Outer Separator Plate
Courtesy of CHRYSLER LLC
4. Install the outer separator plate (1).
2009 Chrysler Town & Country LX
2009 AUTOMATIC TRANSMISSION 62TE - Service Information - Grand Caravan, Town & Country
