Chrysler 62TE - Pinion Cover Cup; Remote Pinion Small Bearing Cup

75. Remove the remote pinion cover (1) from the remote pinion (2).
Fig. 100: Pinion Cover Cup
Courtesy of CHRYSLER LLC
76. Using Remover 8913 (2) and Brace 8915 (1) remove the remote pinion cover bearing cup (3) and
selective shim.
Fig. 101: Remote Pinion Small Bearing Cup
Courtesy of CHRYSLER LLC
2009 Chrysler Town & Country LX
2009 AUTOMATIC TRANSMISSION 62TE - Service Information - Grand Caravan, Town & Country
