Chrysler 62TE - Rear Carrier Bearing Cone; Low;Reverse Spring Compressor Tool

Courtes
y
of CHRYSLER LLC
56. Remove rear carrier assembly (1) from transaxle (2).
Fig. 81: Rear Carrier Bearing Cone
Courtesy of CHRYSLER LLC
57. Remove rear carrier assembly (3) bearing cone using bearing puller 5048 with Jaws 5048-3 and thrust
button 6055.
Fig. 82: Low/Reverse Spring Compressor Tool
Courtesy of CHRYSLER LLC
1 - BEARING PULLER 5048 WITH JAWS 5048-3 AND
THRUST BUTTON 6055
2 - WRENCHES
3 - REAR CARRIER ASSEMBLY
2009 Chrysler Town & Country LX
2009 AUTOMATIC TRANSMISSION 62TE - Service Information - Grand Caravan, Town & Country
