of CHRYSLER LLC
2. Install transfer shaft speed sensor (3) into case.
Fig. 502: Speed Sensor O-Ring
Courtesy of CHRYSLER LLC
3. Install bolt at transfer shaft speed sensor (1) and tighten to 12 N.m (105 in. lbs.).
4. Reconnect the electrical connector.
SENSOR, TRANSMISSION RANGE
REMOVAL
REMOVAL
2009 Chrysler Town & Country LX
2009 AUTOMATIC TRANSMISSION 62TE - Service Information - Grand Caravan, Town & Country
