Chrysler 62TE - Valve Body Bolts

12. Remove the electrical connector (1) at the range sensor (4).
13. Remove the bolt (3) holding the detent spring.
14. Remove the detent spring (2).
Fig. 47: Valve Body Bolts
Courtesy of CHRYSLER LLC
15. Remove valve body bolts (1).
2009 Chrysler Town & Country LX
2009 AUTOMATIC TRANSMISSION 62TE - Service Information - Grand Caravan, Town & Country
