Chrysler 62TE - Remove;Install Piston Retainer; Low;Reverse Piston Retainer-To-Case Gasket

Fig. 88: Remove/Install Piston Retainer
Courtesy of CHRYSLER LLC
64. Remove low/reverse piston retainer (1).
Fig. 89: Low/Reverse Piston Retainer
-To-Case Gasket
Courtesy of CHRYSLER LLC
65. Remove low/reverse piston retaine
r
-to-case
g
asket (2),
g
asket holes must line up (1).
1 - LOW/REVERSE CLUTCH PISTON RETAINER
2 - GASKET
1 - GASKET HOLES MUST LINE UP
2 - LOW/REVERSE CLUTCH PISTON RETAINER
GASKET
2009 Chrysler Town & Country LX
2009 AUTOMATIC TRANSMISSION 62TE - Service Information - Grand Caravan, Town & Country
