Chrysler 62TE - Front Sun Gear Assembly; Remove Front Carrier & Rear Annulus Assembly

29. Remove number four thrust plate (2).
Fig. 60: Front Sun Gear Assembly
Courtesy of CHRYSLER LLC
30. Remove front sun gear assembly (1) and number four thrust washer (2).
Fig. 61: Remove Front Carrier & Rear Annulus Assembly
Courtesy of CHRYSLER LLC
2 - #4 THRUST PLATE (SELECT)
3 - 3 DABS OF PETROLATUM FOR RETENTION
1 - FRONT SUN GEAR ASSEMBLY
2 - #4 THRUST WASHER (FOUR TABS)
1 - #6 NEEDLE BEARING
2009 Chrysler Town & Country LX
2009 AUTOMATIC TRANSMISSION 62TE - Service Information - Grand Caravan, Town & Country
