Chrysler 62TE - Park Pawl Tube Snap Ring 2; Park Pawl Tube

Fig. 107: Park Pawl Tube Snap Ring 2
Courtesy of CHRYSLER LLC
87. Remove the snap ring (1) for the park guide assembly (2).
Fig. 108: Park Pawl Tube
Courtesy of CHRYSLER LLC
88. Remove the park
g
uide assembl
y
(1).
2009 Chrysler Town & Country LX
2009 AUTOMATIC TRANSMISSION 62TE - Service Information - Grand Caravan, Town & Country
