Chrysler 62TE - LC Turning Torque

Fig. 393: LC Turning Torque
Courtesy of CHRYSLER LLC
16. Check turning torque using an inch pound torque wrench. Turning torque should be between 8.0 to 18.0
in-lbs (drag), If more than 18.0 in-lbs (drag) choose a larger shim and recheck turning torque. If less than
8.0 in-lbs (drag) choose a smaller shim and recheck turning torque.
17. Remove transfer gear nut and gear.
Fig. 394: Tool 9908
Courtesy of CHRYSLER LLC
