38. Tap reaction plate (3) down to allow installation of the reverse clutch snap ring (1). Install reverse clutch
snap ring (1).
Fig. 351: Pry Up Reverse Reaction Plate
Courtesy of CHRYSLER LLC
39. Pry up reverse reaction plate (4) to seat against snap ring (2).
2 - SCREWDRIVER
3 - REVERSE CLUTCH REACTION PLATE
1 - SCREWDRIVER
2 - SNAP RING
3 - SCREWDRIVER
4 - MUST RAISE REVERSE REACTION PLATE TO
RAISE SNAP RING
2009 Chrysler Town & Country LX
2009 AUTOMATIC TRANSMISSION 62TE - Service Information - Grand Caravan, Town & Country
