Chrysler 62TE - Crankshaft Position Sensor; Solenoid Connector at Transmission

Fig. 20: Crankshaft Position Sensor
Courtesy of CHRYSLER LLC
12. Disconnect the electrical connector (2) at the crankshaft position sensor (3).
13. Remove hold down bolt (1) at the crankshaft position sensor (3).
14. Remove the crankshaft position sensor (1).
Fig. 21: Solenoid Connector At Transmission
Courtesy of CHRYSLER LLC
2009 Chrysler Town & Country LX
2009 AUTOMATIC TRANSMISSION 62TE - Service Information - Grand Caravan, Town & Country
