Chrysler 62TE - Gear Puller L-4407 A; Output Gear Bearing Cone

Fig. 77: Gear Puller L-4407A
Courtesy of CHRYSLER LLC
53. Using Gear Puller L-4407A (1) and Thrust Button 6055 (3) remove output shaft transfer gear (2) and
select shim.
Fig. 78: Output Gear Bearing Cone
Courtesy of CHRYSLER LLC
1 - BEARING PULLER 5048 WITH JAWS 5048-5 AND
THRUST PAD L-4539-2
2 - WRENCHES
3 - OUTPUT GEAR
2009 Chrysler Town & Country LX
2009 AUTOMATIC TRANSMISSION 62TE - Service Information - Grand Caravan, Town & Country
