Chrysler 62TE - Torque Output Transfer Gear Nut; Turning Torque Output Gear

Fig. 126: Torque Output Transfer Gear Nut
Courtesy of CHRYSLER LLC
15. Install NEW output transfer gear retaining bolt and washer.
16. Install Holder 9739 (1) onto the output transfer gear (2).
17. Tighten output transfer gear retaining bolt to 271 N.m (200 ft. lbs.).
Fig. 127: Turning Torque Output Gear
Courtesy of CHRYSLER LLC
2009 Chrysler Town & Country LX
2009 AUTOMATIC TRANSMISSION 62TE - Service Information - Grand Caravan, Town & Country
