18. Using an inch pound torque wrench, check output shaft turning torque. Output shaft turning torque
should be within 3-8 in. lbs. If the turning torque is too high, install a 0.04 mm (0.0016 in.) thicker shim.
If the turning torque is too low, install a 0.04 mm (0.0016 in.) thinner shim. Repeat until the proper
turning torque of 3-8 in. lbs. is obtained.
Fig. 128: Low/Reverse Clutch Pack
Courtesy of CHRYSLER LLC
19. Install low/reverse clutch pack (1, 2). Leave uppermost disc out until snap ring is installed.
Fig. 129: Low/Reverse Reaction Plate Snap Ring
Courtesy of CHRYSLER LLC
1 - CLUTCH PLATES (5)
2 - CLUTCH DISCS (5)
1 - SCREWDRIVER
2009 Chrysler Town & Country LX
2009 AUTOMATIC TRANSMISSION 62TE - Service Information - Grand Caravan, Town & Country
