Chrysler 62TE - Page 85

20. Install low/reverse reaction plate flat snap ring (2), insure you do not scratch clutch plate (3).
Fig. 130: Low/Reverse Clutch Disc
Courtesy of CHRYSLER LLC
21. Install remaining low/reverse clutch disc (1).
Fig. 131: Low/Reverse Reaction Plate
Courtesy of CHRYSLER LLC
2 - LOW/REVERSE REACTION PLATE FLAT SNAP
RING
3 - DO NOT SCRATCH CLUTCH PLATE
1 - ONE DISC FROM LOW/REVERSE CLUTCH
1 - LOW/REVERSE REACTION PLATE (FLAT SIDE UP)
2009 Chrysler Town & Country LX
2009 AUTOMATIC TRANSMISSION 62TE - Service Information - Grand Caravan, Town & Country
