Chrysler 62TE - Sensor, Pressure Control; Relay at Core Support

Fi
g
. 456: Reaction Support-To-Pump Bod
y
Bolts
Courtesy of CHRYSLER LLC
2. Install and tighten reaction shaft support-to-oil pump housing bolts (1) to 28 N.m (20 ft. lbs.).
SENSOR, PRESSURE CONTROL
REMOVAL
REMOVAL
Fig. 457: Relay At Core Support
Courtesy of CHRYSLER LLC
1. Remove the engine cover.
2. Remove the battery and battery tray. Refer to Electrical
- Engine Systems/Battery System/BATTERY -
Removal .
3. Remove the rela
y
(1) at the core support.
1 - BOLT (6)
2 - PUMP BODY
3 - REACTION SHAFT SUPPORT
2009 Chrysler Town & Country LX
2009 AUTOMATIC TRANSMISSION 62TE - Service Information - Grand Caravan, Town & Country
