Chrysler 62TE - Torque Specifications; Gear Train Measurements

GEAR TRAIN MEASUREMENTS
TORQUE SPECIFICATIONS
Description Metric Standard
Front Sun Gear Bushings 29.55 - 29.60 mm 1.163 - 1.165 in.
Rear Carrier Bushing 29.75 - 30.00 mm 1.171 - 1.181 in.
Overdrive Hub/Shaft Bushing 21.52 - 21.58 mm 0.847 - 0.850 in.
Oil Pump Reaction Support Sleeve 45.27 - 45.31 mm 1.782 - 1.784 in.
Oil Pump Outer Gear to Pump
Pocket
0.089 - 0.202 mm 0.0035 - 0.0079 in.
Oil Pump Outer Gear to Crescent 0.060 - 0.298 mm 0.0023 - 0.0117 in.
Oil Pump Inner Gear to Crescent 0.093 - 0.385 mm 0.0036 - 0.0151 in.
Oil Pump Between Both Gear end
Faces and the Reaction Shaft
Support
0.020 - 0.046 mm 0.0008 - 0.0018 in.
Front/Rear Carrier Pinion end Play 0.15 - 0.61 mm 0.006 - 0.024 in.
Torque Converter Hub Bushing 38.019 - 38.11 1.499 - 1.501 in.
Output Carrier Pinion End Play 0.15 - 0.76 0.006 - 0.030
Direct Clutch Retainer Bushing 39.71 - 39.75 1.563 - 1.565
Low Clutch Retainer Bushing
(Steel)
28.22 - 28.26 1.111 - 1.113
Low Clutch Retainer Bushing
(Brass)
30.01 - 30.03 1.181 - 1.182
DESCRIPTION N.m Ft. Lbs. In. Lbs.
Bolt, Output Transfer Gear 271 200 -
Screws, Low/reverse Piston
Retainer-to-Case
5 - 45
Bolts, Oil Pump-to-Case 30 - 265
Bolts, Reaction Shaft-to-Pump
Housing
27 20 -
Bolts, Stirrup Strap 23 - 200
Bolts, Differential Cover 61 45 -
Bolts, Differential Output Bearing
Cover
12 - 105
Bolts, Remote Pinion Cover 12 - 105
Bolts, Compounder Bearing
Retainer
12 - 105
Nut, Transfer Gear (underdrive
compounder side)
271 200 -
Bolts, Transfer Gear Cover-to-
Case
12 - 105
Pipe Plug, Park Pawl 27 20 -
