Chrysler 62TE - Nut at Transfer Gear

48. Install the Gear Holder 9739 (2) onto the output transfer gear (3).
49. Remove the output transfer gear bolt (1).
Fig. 76: Nut At Transfer Gear
Courtesy of CHRYSLER LLC
50. Grind the staked tabs (1) from the transfer gear (underdrive compounder side).
51. Install the Gear Holder 9739 (1) onto the transfer gear (underdrive compounder side) and remove the nut.
52. Lift the transfer
g
ear from the underdrive compounder shaft.
2009 Chrysler Town & Country LX
2009 AUTOMATIC TRANSMISSION 62TE - Service Information - Grand Caravan, Town & Country
