Chrysler 62TE - 2;4 Clutch Return Spring; 2;4 Clutch Pack

34. Remove 2/4 clutch retainer (1).
Fig. 65: 2/4 Clutch Return Spring
Courtesy of CHRYSLER LLC
35. Remove 2/4 clutch return spring (1).
Fig. 66: 2/4 Clutch Pack
Courtesy of CHRYSLER LLC
1 - 2/4 CLUTCH RETAINER
2 - 2/4 CLUTCH RETURN SPRING
NOTE: The 2/4 Clutch Piston has bonded seals which are not individually
serviceable. Seal replacement requires replacement of the piston
assembly.
1 - 2/4 CLUTCH RETURN SPRING
2009 Chrysler Town & Country LX
2009 AUTOMATIC TRANSMISSION 62TE - Service Information - Grand Caravan, Town & Country
