Chrysler 62TE - Planetary Gear Set Disassembly

Fig. 364: Helical Shim
Courtesy of CHRYSLER LLC
2. Remove the helical shim (1).
Fig. 365: Planetary Gear Set
Courtesy of CHRYSLER LLC
2009 Chrysler Town & Country LX
2009 AUTOMATIC TRANSMISSION 62TE - Service Information - Grand Caravan, Town & Country
