Chrysler 62TE - Selectable Shim & Transfer Gear; Torque Transfer Gear Nut

Fi
g
. 391: Selectable Shim & Transfer Gear
Courtesy of CHRYSLER LLC
14. Install the selectable shim (3), transfer gear (2) and the transfer gear nut.
Fig. 392: Torque Transfer Gear Nut
Courtesy of CHRYSLER LLC
15. Using Holder 9739 (1) tighten transfer gear nut to 271 N.m (200 ft. lbs.).
NOTE: The selectable shim will determine turning torque.
2009 Chrysler Town & Country LX
2009 AUTOMATIC TRANSMISSION 62TE - Service Information - Grand Caravan, Town & Country
