Chrysler 62TE - Transfer Gear Cover; Oil Scavenger

Fi
g
. 72: Transfer Gear Cover
Courtesy of CHRYSLER LLC
42. Remove transfer gear cover-to-case bolts (2).
43. Remove transfer gear cover (1).
Fig. 73: Oil Scavenger
Courtesy of CHRYSLER LLC
44. Remove the oil scaven
g
er (2).
2009 Chrysler Town & Country LX
2009 AUTOMATIC TRANSMISSION 62TE - Service Information - Grand Caravan, Town & Country
