Chrysler 62TE - Front Mount Bracket Bolts

Fig. 30: Front Mount Bracket Bolts
Courtesy of CHRYSLER LLC
33. Remove the front mount bracket bolts (1).
34. Remove the heater line bracket bolt (3).
Fig. 31: Transmission Front Mount Bracket To Engine Bolt
NOTE: The three bolts on the left side of the front bracket hold the starter in
place, ensure starter is supported.
2009 Chrysler Town & Country LX
2009 AUTOMATIC TRANSMISSION 62TE - Service Information - Grand Caravan, Town & Country
